Brand:
CISCO
-
Dimensions (W, L, H), mm:268 x 185 x 44 mm
-
Switch type:Fixed Port
-
Main ports, typ:8x 10/100/1000Base-T PoE+ with 120W power budget
-
Power over Ethernet (PoE):PoE+ (120W); 8 ports
-
Uplink ports:2x 1G copper/SFP combo ports
-
Free (10GB) slots:-
-
Stackable:-
-
Fans_TEXT:Fanless
-
Routing:Layer 3 static routing
-
Memory (Flash, RAM):512 MB (Flash), 1 GB DDR4 (DRAM), 1.5 MB (Packet buffer)
-
Routing/switching capacity, Gbps:20 Gbps
-
Throughput, Mpps:14.88 Mpps
-
MAC addresses:8000 addresses
-
VLAN (number, standards):Support for up to 255 active VLANs simultaneously; Port-based and 802.1Q tag-based VLANs, Management VLAN, Guest VLAN, Auto Surveillance VLAN (ASV), Voice VLAN
-
L2 network standards:IEEE 802.3, IEEE 802.3u/ab/ad/z/x/af/at; IEEE 802.1D (STP)/1Q/p VLAN/w RSTP/s Multiple STP/X Port Access Authentication; RFC
-
IPv6 functionality:IPv6 host mode, IPv6 over Ethernet, Dual IPv6/IPv4 stack, IPv6 Neighbor Discovery (ND), IPv6 stateless address auto-configuration, Path MTU discovery, DAD, ICMP v6, IPv6 over IPv4 network with ISATAP
-
Mounting option:Rackmount
-
:100 to 240V 50 to 60 Hz, internal
-
:SSL, SSH, IEEE 802.1X (authenticator role): RADIUS authentication, guest VLAN, single/multiple host mode, and single/multiple sessions; STP; SCT; SSD, Trustworthy systems, Port security, Storm control, DoS prevention, ACLs
-
:8 hardware queues; Port based, 802.1p VLAN priority based, IPv4/v6 IP precedence/Type of Service (ToS)/DSCP based, Differentiated Services (DiffServ), classification and re-marking ACLs, trusted QoS
-
:10
-
:Network PnP, Web user interface, Cisco Business mobile app, Cisco Business Dashboard, SNMP, MIBs, RMON, DHCP, CLI and etc.
