Brand:
DELL
-
Others:1 RJ45 console/management port with RS232 signaling, 1 RJ45 micro-USB-B console port, 1 RJ45 10/100/1000Base-T management Ethernet port
-
Dimensions (W, L, H), mm:431 x 457 x 44
-
Switch type:Fixed Port
-
Main ports, typ:28x 10GBase-T
-
Power over Ethernet (PoE):No
-
Uplink ports:2xQSFP28
-
Free (10GB) slots:No
-
Stackable:No
-
Fans_TEXT:4x Fan module
-
Fans:Yes
-
Routing:Layer 3 Advanced
-
Memory (Flash, RAM):RAM: 4 GB
-
Routing/switching capacity, Gbps:960 Gbps
-
Throughput, Mpps:720 Mpps
-
MAC addresses:272K (in Scaled L2 mode)
-
VLAN (number, standards):802.1Q VLAN Tagging, GVRP; 4K Layer 2 VLANs; 500 Layer3 VLANs
-
L2 network standards:IEEE compliance: 802.1AB, 802.1s, 802.1w, 802.3ab, 802.3ad, 802.3ae, 802.3ba, 802.3i, 802.3u, 802.3z, 802.1D, 802.1p, 802.1Q, 802.1Qbb, 802.1Qaz, 802.1X, 802.3ac, 802.3bj, 802.3x, 802.1t
-
L3 network standards:OSPF
-
IPv6 functionality:General IPv6 protocols are supported.
-
Mounting option:Rackmount
-
:Redundant, hot-swappable power supplies
-
:RADIUS, Radius and IPv6, SSHv2, Security Architecture for IPSec, IPSec Authentication Header, ESP Protocol
-
:Access Control Lists, Prefix List, Route-Map, Rate Shaping (Egress), Rate Policing (Ingress), Scheduling Algorithms (Round Robin, Weighted Round Robin, Deficit Round Robin, Strict Priority), Weighted Random Early Detect
-
:30
-
:SNMPv1/2; SSHv2; FTP, TFTP, SCP; Syslog; Port Mirroring; RADIUS; 802.1X; Support Assist (Phone Home); Netconf APIs; XML Schema; CLI Commit (Scratchpad); sFlow
